    PVC Coated Welded Wire Mesh Panels For Area Protection , Eco Friendly

    Ask Lasest Price
    Brand Name : BROS
    Model Number : Bros-0504
    Certification : ISO 9001:2008
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets Per week
    Delivery Time : 5-20 day after the deposit is received
    • Product Details
    • Company Profile

    PVC Coated Welded Wire Mesh Panels For Area Protection , Eco Friendly

    PVC Coated Welded Triangle Bending Garden Fence For Area Protection


    Product Description

    PVC coated welded wire mesh is made of quality welded low carbon steel wire mesh galvanized before,then coated with PVC powder or PE powder.The coated layer is even,strong adhere siveness and bright luster with long live good anti-corrosive property. All kinds of colors can be coated according to customers' special requirements.The panel fixed with anti-thief post,peach post,round post or square post by fittings.people normally use it in garden, road side,residental,playground and etc.

    Wire diameter: 3.0-6.0mm


    PVC coating thickness: (pvc spraying)0.15-0.2mm; (pvc coat) 0.5-1mm


    Aperture size: 50x100mm, 50 x 150mm, 50 x 200mm, 75 x 150mm


    Forms of corrosion resistance: electric galvanized +pvc spraying /pvc dipped coated, hot-dip galvanized


    Color: RAL 6005 green or as your custom design


    Characteristics: high strength , good steel property, nice and bright appearance, easy to install and maintenance


    Application: widely used for protection for road, highway, municipal, railway, garden, residential area, airport, residential district, seaport, feeding and husbandry ,military base etc.


    Fence panel specification
    Panel size (height x length)Wire diaMesh sizeSurface treatmentFolds ( or no folds as your request)
    1.03m3mm-6mm

    50x50mm, 50x75mm

    50x100mm

    50x150mm

    50x200mm

    55x100mm

    75x200mm

    60x150mm

    Or as your request

    1. Electro GI+PVC coated
    2. Electro GI+ painting(Spraying)
    3. hot-dipped GI only
    4. Hot-dipped GI +PVC coated or painting
    2
    1.23m2
    1.5m2 or 3
    1.53m2 or 3
    1.7m3
    1.73m3
    1.8m3 or 4
    1.93m3 or 4
    2.0m4
    2.03m4
    2.4m4

    specification of fence post
    Post StylePost SizePost height
    Rectangle Post40*60*1.2mm

    1.63m

    1.83m

    2.1m

    2.13m

    2.2m

    2.23m

    2.4m

    2.53m

    2.6m

    2.63m


    40*60*1.5mm
    40*60*2mm
    Square Post40*40*1.2mm
    40*40*1.5mm
    60*60*2mm
    60*60*2.5mm
    Peach post50*70mm
    70*100mm
    Round post38mm*1.2mm
    40*1.5mm
    42*1.5mm
    48*2mm
