Commercial Tubular Security Picket Steel Fence Panels With Black
Color Spraying
Product Description
Tubular picket fence utilizes standard a multiple layer coating
process that ensures corrosion protection, durability and a great
appearance for years to come.
Tubular picket fence system will complement any architectural
design while providing elegance, security, and long lasing value.
For the top and rails the customer has different options
Material: Galvanized steel pipe
Specification
| Material | hot dipped galvanized steel pipe |
| Surface treatment | Powder coated |
| Horizontal pipe | 40x40x1.5mm;40x40x1.2mm;;32x32x1.2mm |
| Vertical pipe | 25x25x1.2mm;25x25x1.0mm;19x19x1.0mm;16x16x1.0mm |
| Head up and down | 150mm or according to your requirements |
| Post | 50x50x1.5mm;60x60x1.5mm;75x75x2.0mm |
| Panel height | 1.2m;1.5m;1.8m;2.0m ,we can do according to your requirements |
| Panel length | 2.4m,2m ,3m, 5m,etc. we can do according to your requirements |
| Link way | welded or self-assemble |
| Product name | Tubular security picket steel fence panels |
| Components | Panel (Horizontal rail/ tubular, vertical picket/tubular), Post,
Clamps, Bolts& Nuts |
| Manufacture | 1, cutting the tubes short >> 2, drilling holes on horizontal
rails >> 3,Welded the rails with tubes >> 4,powder coating >> 5,
packaging The above is just a general process. And the detailed product flow can be different according to
different products specification |
| Packaging | * Panel-Metal Pallet wrapped with cardboard plate and then wrapped
with plastic film * Post- Wrapped with PP bags, then put on pallet ,wrapped with
plastic film * Accessories- Carton * Customized packing is available |
The main manufacture process:
Assembled:
1>Cut Shot2>Punching Holes3>Acid-Washing4>Rich-Zinc
Powder Coating5>Polyester Color Powder
Coating6>Assembly7>packing
Welded:
1>Cut Shot2>Welded3>Acid-Washing4>Rich-Zinc Powder
Coating5>Polyester Color Powder Coating 6>packing
Surface Treatment: : Electro-galvanized, Hot-dipped Galvanized then Powder Coated
Top style: Flat top, spear top, flush top, bent top, separate top.
Feature
1. Firm, durable, jointed strongly, well structured,natural beauty,
quick and easy installation.
2. It is in accordance with the standard of environmental
protection, does not pollute the environment. It has been solved
the problem of traditional products pollution of buildings.
3. Low basic requirements, long service life, green environmental
protection.
4. Good weather resistance, salt spray resistance and humidity
resistance, which is applicable for different areas.
Application
Widely used in villas, community, gardens, schools, factories and
other flower beds, lawns, industrial and mining enterprises,
financial institutions, sports stadiums, convention centers,
squares, roads, balconies, residential .
