PVC Coated Barbed Wire Double Strand 2MM Barbed GI Wire Mesh
Description of Barbed Wire
Barbed wire,also known as barb as a type of fencing wire
constructed with sharp edges or points arranged at intervals along
the strand(s).
It is divided into single strand and double strands.And double
strand also including single wire and double wire.
According to the surface treatment,it including galvanized one or
pvc coated for customer choose.
1) Material: high-quality low-carbon steel wire (zinc coating, PVC, PE, spray
plastics) PVC wire, with blue, green, yellow color.
2) Features: It can be installed to achieve the result of frightening and
stopping aggression. Wire with galvanization and PVC coating can be
prevent corrosion.
3) Usage: Barbed Wire Barbed Wire can be hooked at the bracket on tope of
fence in order to reinforce the security. mainly serves in
protecting of grass boundary, railway, highway and also widely used
in millitary, jail, industry, agriculture, animal husbandry,
dwelling house, plantation for fencing.
4) Technical information of Galvanized Barbed Wire:Electro Galvnaized and Hot dipped Galvanized.
5) Technical information of PVC Coated Barbed Wire: -Inner of PVC Coated barbed wire can be galvanized iron wire of
black annealed iron wire. -A variety of colors like green, blue,
yellow, orange, gray, is available. -Tensile strength of standard
PVC coated barbed wire is 30-45 kg force.
Specification
Gauge of
Strand and Barb in B.W.G. | Approximate Length per Kilo in Meter |
| Barbs Spacing 3" | Barbs Spacing 4" | Barbs Spacing 5" | Barbs Spacing 6" |
| 12x12 | 6.0617 | 6.7590 | 7.2700 | 7.6376 |
| 12x14 | 7.3335 | 7.9051 | 8.3015 | 8.5741 |
| 12-1/2x12-1/2 | 6.9223 | 7.7190 | 8.3022 | 8.7221 |
| 12-1/2x14 | 8.1096 | 8.814 | 9.2242 | 9.5620 |
| 13x13 | 7.9808 | 8.899 | 9.5721 | 10.0553 |
| 13x14 | 8.8448 | 9.6899 | 10.2923 | 10.7146 |
| 13-1/2x14 | 9.6079 | 10.6134 | 11.4705 | 11.8553 |
| 14x14 | 10.4569 | 11.6590 | 12.5423 | 13.1752 |
| 14-1/2x14-1/2 | 11.9875 | 13.3671 | 14.3781 | 15.1034 |
| 15x15 | 13.8927 | 15.4942 | 16.6666 | 17.5070 |
| 15-1/2x15-1/2 | 15.3491 | 17.1144 | 18.4060 | 19.3386 |
| Type | Wire Gauge (BWG) | Barb Distance (cm) | Barb Length (cm) |
Electric Galvanized Barbed Wire; Hot-dipped galvanized barbed wire | 10BWG x 12BWG |
7.5-15 |
1.5-3 |
| 12BWG x 12BWG |
| 12BWGx 14BWG |
| 14BWG x 14BWG |
| 14BWG x 16BWG |
| 16BWG x 16BWG |
| 16BWG x 18BWG |
PVC coated barbed wire
| Before coating | After coating |
7.5-15 |
1.5-3 |
| 1.0mm-3.5mm | 1.4mm-4.0mm |
| BWG11BWG-20BWG | BWG8BWG-17BWG |
| BWG11BWG-20BWG | BWG8BWG-17BWG |
PVC Coating thickness: 0.4mm-0.6mm; different colors or length are
available at customers request.
|
Package
1) In coil of 25 kilos or 50 kilos by bulk, lined with PVC strips, then
wrapped with PVC or hessian cloth.
2) Packing with carton box or wooden pallet
3) Wooden handle
3) Special packaging is available.
